Magnetic Lifter 500kg

The Magnetic Lifter 500kg serves as a prevalent magnetic fixture in machinery and mold factories, along with various machining fields. It significantly enhances the gripping efficiency of magnetic steel materials. Utilizing high-performance rare earth material Ndfeb (with N>40) as its core, this lifter employs a manual handle to rotate the chuck. This rotation alters the magnetic system within the Ndfeb core, allowing for the secure holding or release of the workpiece during processing.

Send Inquiry PDF DownLoad

Product Description

Utilizing high-performance permanent magnet material Ndfeb (ND-FE-B) as its core, this product boasts a smaller size, increased lifting force, and long-lasting magnetic strength.Operates without the need for electricity, eliminating concerns about power supply requirements.The Magnetic Lifter 500kg features an optimized magnetic circuit design, resulting in almost zero remanence.Its professionally designed appearance enhances the product's aesthetics and visual appeal.

Product Specification

Type	HG150	HG300	HG350	HG500
Load Capcity	150kg	300kg	350kg	500kg
Max.Height	720mm	900mm	1300mm	900mm
Min.Height	280mm	280mm	350mm	280mm
Table Dimension	81550050mm	81550050mm	91050050mm	91050050mm
Number of Foot Pedal Strokes to Reach Max.Height	≤20	≤30	≤40	≤30
Selt Weight	45kg	80kg	106kg	86kg

Feature And Application

Usage:

1. Place the workpiece on the suction table and insert the spanner into the shaft hole to hold the workpiece ready for processing.

2. In order to prevent any possible accidental rotation of the spanner in the magnetizing state, the spanner should be removed before processing.

3. After the workpiece is processed, insert the spanner into the shaft hole and turn counterclockwise for 180 to "OFF" to complete demagnetization and remove the workpiece safely.

Maintenance:

1. Clean the surface of the suction cup before use to avoid scratches affecting the accuracy.

2, the use of ambient temperature in -40C- 50C, is strictly prohibited to knock, in case of magnetic force reduction.

3, after using the working face coated with anti-rust oil, to prevent corrosion.

Product Details

The Magnetic Lifter 500kg operates based on the principles of magnetic flux continuity and the superposition principle of magnetic fields. Its magnetic circuit is structured into multiple magnetic systems. By enabling relative movement among these systems, the magnetic field intensity on the working magnetic poles can be adjusted—either increased or decreased—to achieve the objective of gripping and releasing objects.

Magnetic Lifter 500kg
